1.Video processor and light cold source machine
1.Lamp : LED light (80W white)
2.Power: 220-240V; 50-60HZ
3.Color temperature :≥5300K
4.Video signal output: HDMI x2,DVI
5. Sharpness adjustment :0-3 grade
6.Withe balance : Auto white balance/ Manually white balance
7.Gain function: 1-3 grade
8.Air pump pressure : 30-60Mpk,
9.Image side :Octagon/round
10.Air flow : 4-10 L/min
11.Package size :55*46*50cm (G.W.:16kgs)
12.Main Function:
Brightness , Contrast,Tone,Saturation 0-100 grade can be adjustment .
Large screen frozen, small screen display continue .Digital widescreen and picture in picture function.
With USB interface support picture and video record function
Can add only gastroscope /bronchoscope in future if hospital need .
2.LCD Monitor
1.Display size: 24”
2.Power Supply: External Power Supply 12V
3.Resolution: 1280x1024
4.Display Ratio: 16:9
5.Color: 16.7M
6.Camoration Brightness: 180士10 cd/m
7.Max.Brightness: 400 cd/m
8.Package size: 44*36.5* 16.5cm (G.W.:6.0kgs)
3.Equipment vehicles
1.Size: 500 * 700 *1350mm
2.Package size:118.5*63.5*22cm (G.W.:28kgs)
