ECG
Lead Mode: 5 Leads (l, ll, l1,AVR, AVL ,AVF,V)
Gain: 2.5mm/mv,5.0mm/mv, 10mm/mv, 20mm/mv
Heart Rate: 15 300 BPM (Adult); 15-350 BPM (Neonatal)
Resolution: 1 BPM
Accuracy:+1%
Sensitivity >200 uV(Peak to peak)
ST measurement range: -2.0~+2.0 mv
Accuracy: -0.8mV~+0.8mV:+0.02mV or +10%，which is greater
Other Range: unspecified
Sweep speed: 12 5 mm/s, 25mm/s,50mm/s
Bandwidth:
Diagnostic: 0.05~130 Hz
Monitor.
0.5~40 Hz
Surgery:
1~20 Hz
TEMP
Measure and Alarm Range: 0 ~50 C
Resolution:0.1C
Accuracy: +0.1C
SPO2
Measuring Range: 0 ~100 %
Resolution: 1%
Accuracy: 70%~100%(+2 %)
Pulse Rate: 20-250 BPM
Resolution: 1 BPM
Accuracy:+3 BPM
NIBP
Method: Oscillometry
Measure mode: Manual,Auto,STAT
Unit: mmHg, kPa
Measure and alarm range:
Adult Mode
SYS40 ~ 280 mmHg
DIA10 ~ 225 mmHg
MEAN 20~ 240 mmHg
Pediatric Mode
SYS40 ~ 220 mmHg
DIA10 ~160 mmHg
MEAN 20 ~ 170 mmHg
Neonatal Mode
SYS40 ~135 mmHg
DIA10 ~ 100 mmHg
MEAN 20 ~ 110 mmHg
Resolution: 1mmHg
Accuracy; +5mmHg
RESP
Method: Impedance between RA-LL or RALA
Measurement Range:
Adult: 10~ 120 BrPM
Neonatal/ Pediatric: 7 ~150 BrPM
Resolution: 1 BrPM
Accuracy: +2 BrPM
Standard Paramenters
ECG,RESP,TEMP,NIBP, SPO2,PR
Optional Parameters
Recorder ( Printer)
Central monitoring system
Dual lBP
Etco2
12-lead ECG
Nellcor SpO2
Sun Tech NIBP
