1. Double CPU safer infusion
2. Occlusion detector safter infusion
3. Big brightness LCD display visually
4. Occlusion, air-in-line, audio visual alarm volume:10 settings
5. Numeric keypad very user friendly
6. 3000mAh lithium battery backup life:≥10 hours
1. Double CPU safer infusion
2. Occlusion detector safter infusion
3. Big brightness LCD display visually
4. Occlusion, air-in-line, audio visual alarm volume:10 settings
5. Numeric keypad very user friendly
6. 3000mAh lithium battery backup life:≥10 hours
lnfusion Mode
Volume Mode、Time Mode、Drug Mode、Bolus Mode
Ⅳ Sets
Standard single use V sets
10、15、20、60d/mL with diameter 3.4 - 4.5mm
Flow Rate
1.0ml/h~1200ml/h; 1.Od/min～400d/min
lncrement
1.0-99.9mI/h with 0.1ml/h; 100-1200mI/h with 1ml/h
Deviation
Flow Rate: ≤土5%(after calibration)
Purge Rate
600ml/h，displaying purge volume
KVO
0.1ml/h-5.0ml/h，adjustable
Night Mode
Night Mode
No operation for 5mins
LCD brightness lover automatically
Occlusion Pressure
Occlusion pressure detection
40~130KPa
0~9 levels adjustable
Detection
dynamic pressure value display
Air bubble Detection
Ultrasonic detection
≥50uL
Single bubble volume: 50 -30OuI
0～9 levels adjustable
Motor Anti-reverse Function
Anti-reverse function to prevent upstream
IV Set
Open system can accept all kinds of IV Set after calibration
Self-Testing
Self-Testing when start up and during infusing
Audio Visual/Alarm Message
Air bubble
occlusion
door open
infusion finish
standby time expired
battery low
battery empty
battery disengaged
AC Power disengaged
motor error
pump error
pressure sensor error
parameter error
system abnormal
Power Supply
AC:100V ~ 240V
50Hz/60Hz
≤ 25VA
Battery
Rechargeable Lithium battery: DC11.1V
300OmAh;operating time: ≥ 10 hours
@25ml/h，displaying remaining battery
Operation Conditon
Termperature:5°C-40°C
Relative humidity.20%-80%
Atmospheric pressure:70-106KPa
Transportation & Storage
Temperature:-20C-55℃
Relative humidity:10% ~ 95%
Atmospheric pressure:50-106KPa
Classification
Type CF
Class l，IPX3
ISO13485
CE
IEC60601
