1.Application: infants and adults.
Tidal Volume setting 50~2500mL(Optional 20~2500mL)
2.10.4”TFT touch screen
3.Ventilation Mode: VCV, PCV, SIMV-VC + PSV, BackupSPONT/CPAP + PSV,Standby .
Optional: SIMV-PC + PSV, DuoPhasic/APRV + PSV
4.100% 02 suction, 2min .
5.Easily removable and sterilizableflow sensor &exhalation valve module
Built-in: Active expiratory PEEP valve,02 & Air mixture device,Synchronized nebulizer,Battery
6.Optional:air-compressor
Measurement
1. Pressure values: Ppeak,Pplat, Pmean,Pmin, PEEP
2. Volume/Flow values: Vti, Vte, MV, MVspont
3. ftotal, fspn, FiO2,
4. Optional loops: Pressure - Volume, Volume - Flow
5. Optional:EtCO2,Sp02,Rinsp, Cdyn and RSBI
Alarms
MV, Paw, Vte, Rate,FiO2, Mains failure, Battery low, Battery
discharged, Air supply failure, 02 supply failure, Apnea,
Circuit occlusion,EtCO2
