Item | Specification |
Xray Tube Assembly | Focus: small focus 0.6mm; large focus 1.2mm |
Anode heat capacity: 240KHU |
The maximum voltage: 150KV |
Maximum current :630mA |
X-ray high-frequency high-voltage generator | Power Output 50KW |
Tube Voltage 40-150KV |
Tube Current 10-630mA |
Power Voltage: 380V |
Bed and U-shape frame system | Mobile Radiography bed (L2000mm*W700mm*H670mm) |
U-arm Column height 2200mm |
U-arm Moving up and down: 400mm-1700mm |
U-arm Rotation range: 0°～90° |
U-arm Lateral distance from the ground ≥650mm |
U-arm Lifting stroke: ≥ 1150mm |
U-arm SID Range: 1000mm～1800mm |
