Item | Specification |
Xray Tube Assembly | Focus: small focus 0.6mm; large focus 1.2mm |
Anode heat capacity: 240KHU |
The maximum voltage: 150KV |
Maximum current :500mA(630mA optional) |
X-ray high-frequency high-voltage generator | Power Output 50KW |
Tube Voltage 40-150KV |
Tube Current 30-500mA(10-630mA optional) |
Power Voltage: 380V |
Bed and chest frame system | Mobile Radiography bed (L2000mm*W700mm*H670mm) |
Column Up and down movement range:0-1400mm |
Column horizontal movement range:1600mm |
Chest bucky stand up and down movement range:0-1400mm |
Chest bucky stand and the tube are synchronized to move up and down |
Tube rotation Angle:±135° |
