6. Four encoders, knob design, quick and convenient operation
7. Support multi-language switching
8. Movie playback: 256 frames, can be played back frame by frame and pause playback，pause playback can be used for image preservation and measurement
9. Measurement: Professional measurement software;
10. Applicable Object:
Middle and small animals, liver, gallbladder, spleen, kidney, bladder, uterus and other tissues and organs inspection and diagnosis of lesions.
Pregnancy test and measurement of back fat thickness in large animals such as cattle, sheep,horses and pigs
Display
15 inch LED screen
Probe Interface
Dual probe interface
with automatic identification function
Battery Capacity
removable lithium battery /6000 mAh
Display mode
B
B+B
4b
B + m
m
Operation interface
easy to understand
ready to use
Movie playback
256 frames
Language
Chinese
English
Spanish
Portuguese
Russian
French
Electron focusing
four stage electron focusing
Body position markers
18
Frequency conversion
All probes support five-stage frequency conversion
Image mirror
upper and lower mirror
left and right mirror
black and white flip
Measurement
Professional software measurement package
Character display
date，clock，name
gender
age
doctor，hospital
Gain range
0-135db
Interface
video interface
two USB interface
DICOM interface
VGA interface
power interface
Permanent storage
16G built-in storage
can also be connected to external U disk storage
Grey scale
level256
Dynamic range
0-135db
Puncture guidance
puncture line position can be adjusted
Function
rock positioning and dynamic target tracking
Front process
variable aperture
dynamic trace change
dynamic digital filtering
etc
After the process
8 kinds of y correction
line correlation
16 level frame correlation
point and linecorrelation
linear interpolation
digital spatio-temporal filtering
digital edge enhancement
8 kindsof false color processing
etc
Blind area
≤4
Maximum display depth
300mm
Geometric accuracy
transverse ≤5%
longitudinal ≤5%
Resolution
lateral ≤2mm
axial ≤1mm
Display magnification
16 display modes
Lesion diagnosis is more accurate
Enhanced depth display
Host size
360mm(L)*355mm(W)*65mm(H)
