1. To meet most of the endoscopic surgery, such as laparoscopy.
2. output power accuracy is high,the use is safer
3. update function on this APCS/ Instant Response.The system can do a veryfast recognize & feedback to different tissue resistance, and do powercompensation in very short time, so Doctor can never feel the un-smoothcutting in the operation.
4.s oft type cutting, a precise cutting, minimum the harm on the surroundingtissue, applicable to maxillofacial surgery and other Plastic and cosmeticsurgery which need precise and soft cutting
5. Bipolar Mode more detail classified: PRECISE/STANDARD/MARCO.
1. To meet most of the endoscopic surgery, such as laparoscopy.
2. output power accuracy is high,the use is safer
3. update function on this APCS/ Instant Response.The system can do a veryfast recognize & feedback to different tissue resistance, and do powercompensation in very short time, so Doctor can never feel the un-smoothcutting in the operation.
4.s oft type cutting, a precise cutting, minimum the harm on the surroundingtissue, applicable to maxillofacial surgery and other Plastic and cosmeticsurgery which need precise and soft cutting
5. Bipolar Mode more detail classified: PRECISE/STANDARD/MARCO.
Maximum Cut Power
200w
Mono Cut Mode
Low (0-300W load 300Q)
PURE(0-100W load 500Q)
BLEND (0-100W load 300Q)
Maximum Coagulation Power
120w
Coagulation Mode
SOFT (0-120W load 500Q)
FORCED (0-100W load 500Q)
SPARY (0-10oW load 500Q)
Maximum Bipolar Power
80w
Bipolar Mode
PRECISE (0-50W load 100Q)
STANDARD (0-80W load 100Q)
MACRO(0-8oW load 100Q)
Integrated Waterproof Design
Yes
Self-check Function After Power-on
Yes
power-on 3-5s
will do a system self-test completely
display by one small monitor
Endoscopic Function
YES
Negative Plate detection
YES
Single/ Double type pad
Fault( Sound and Light )Alarm
YES
Pencil Error Operation Alarm
YES
Automatic Power Compensation(APCS) Instant Respons
YES
Min adjustable step Power
Monopolar is 5w step
Bipolar is 1W step
Wide Voltage Design
100V-240V
Working Frequency
330/430KHZ 1MHz
Product Size
380*330*145mm
Product Weight
12KGS
