Size: L2050/1450*W980* H680-900mm (with mattress )
Electrical delivery bed , 3 sections on surface, four functions: back rest function, up and
down function, trendelenburg and reverse trendelenburg, without battery without CPR
function , with IV pole
Functions: Four functions controlled by three electric motors
1.Back rest angle: 0-80°, controlled by electric motor.
2.Up and down function: height adjustment from 680-900mm, controlled by electric motor
3.Trendelenburg 0-10° (土 1°) ,and reverse trendelenburg 0--10° (土1°) , controlled by
one electric motor.
Size: L2050/1450*W980* H680-900mm (with mattress )
Electrical delivery bed , 3 sections on surface, four functions: back rest function, up and
down function, trendelenburg and reverse trendelenburg, without battery without CPR
function , with IV pole
Functions: Four functions controlled by three electric motors
1.Back rest angle: 0-80°, controlled by electric motor.
2.Up and down function: height adjustment from 680-900mm, controlled by electric motor
3.Trendelenburg 0-10° (土 1°) ,and reverse trendelenburg 0--10° (土1°) , controlled by
one electric motor.
1.Main material of this bed is epoxy coated steel with ABS head/foot boards easy to
remove for emergency
2.Removable Head and foot board, easy to operate.
3.Removable remote control
4. Detachable foot section
5.8cm &20cmthickness mattress with PU cover and zippers at each section, easy to clean
6.Mobile on four 125mm diameter swivel casters with individual brake system(foot operated).
7.ABS side rails on both side of this bed, easy and fast to operate (optional side rails&color : wooden)
8.Integrated fluid basin
9.With pink foam leg support (optional : wrapped leg support)
10.Safe working load 200k
Optional functions & parts :
1.With compact Laminate platform
2.With black foam leg support
3.With IV pole
1.Main material of this bed is epoxy coated steel with ABS head/foot boards easy to
remove for emergency
2.Removable Head and foot board, easy to operate.
3.Removable remote control
4. Detachable foot section
5.8cm &20cmthickness mattress with PU cover and zippers at each section, easy to clean
6.Mobile on four 125mm diameter swivel casters with individual brake system(foot operated).
7.ABS side rails on both side of this bed, easy and fast to operate (optional side rails&color : wooden)
8.Integrated fluid basin
9.With pink foam leg support (optional : wrapped leg support)
10.Safe working load 200k
Optional functions & parts :
1.With compact Laminate platform
2.With black foam leg support
3.With IV pole
