Output: Biphasic Truncated exponential
Energy Sequence: 150,150, 200J
Charge Time: 8 sec.to 150J;10 sec. to 200 J (New battery)
Analysis Time: 9 sec.
The maximum time from the initiation of rhythm analysis to readiness for discharge with a new battery:Less than 20 seconds
The maximum time from the initiation of rhythm analysis to readiness for discharge after 6 shocks:Less than 25 seconds
The maximum time from initially switching power on to readiness for discharge: Less than 20 seconds
Audible Prompts: 22 audible prompts
Visual Prompts: LED prompts;Automatic Self-test
Output Energy Accuracy: ±15% into any impedance from 25 to 1750
Controls: Two buttons - On/Off, Shock
The Maximum Voltage: 1200土50V
Output disabled when the patient impedance is outside limits: 200 to 200Q
Battery
Part No: CR123A-4x2
Non-rechargeable: 2.8 Ah
Capacity: 100 discharges at 200 Joules or 120 discharges at 150 Joules
Shelf Life (25C±15°C): 5 years standby (after installation)
Physical: 22 audible prompts
Dimensions: 303×216x89 mm
Weight: 2.0kg
Operating Temperature: 0°C to 40°C
Operating Humidity: Relative humidity between 30% and 95%(non-condensing)
Storage Temperature(without battery): -20°C to 55℃
Storage Humidity: Up to 93%(non-condensing)
