Display
Display Type: 8 inch high resolution LCD displaysweep Speed: 25mm/sec
Information: HR, Lead/Pads，On/Off Alarm,Sp02，AEDFunctions and Prompts,Alarm Se-
lection and Limits, Delivered Energy.
Defibrillator
Waveform: Biphasic
Charge Time: Less than 7 seconds with a new fully charged battery.
Energy Display: Monitor display indicates both selected and delivered energy.
Charge Prompt Type: Voice and visual prompts.
Electrode lmpedance Measurement Range: 0-250 ohms.
ECG Monitoring
Patient Connection: 5 -lead ECG cable, or 3-lead ECG cable,paddles.
Lead Selection: Displayed on monitor, paddles,l， ll,II1, AVR,AVL,AVF,V.
ECG Size:0.25,0.5,1,1.5,2,4 cm/mv diplay on monitor.Heart Rate: 20- -300BPM.
Heart Rate Alarm: On/Off displayed on monitor，user-selectable.
Smart Alarms: Beeper/voice prompts indicate shockablerhythm.
Recorder
Paper: 50mm thermal.
Speed:12.5mm/sec, 25mm/sec,50mm/sec. User- selectable 6--second delay.
Printing Method:High-resolution, thermal print head.
Print-out Modes:Manual or automatic, user-configurable.
On/Off Control: Front panel and paddle.
Automatic Function: 9-seconds recording initiated by alarm activation or defibrllator chargeor defibillator discharge.
Battery
Type: Rechargeable,Ni-MH battery,12V.
Operating Time:For a new, fully charged battery: 60 defirillator discharges at maximumenergy, or 3 hours minimum of continuous ECG monitoring.
Additional parameters will effect operating time with different functions.AED Mode
AED Function: Auto analyze and charge x3 with programmable auto energy level selection,screen prompts, and voice prompts.
Shockable Rhythms: Ventricular firillation with amplitude >=200Uv, ventricular tachycardiawith rates >=140bpm,
and QRS complex wave duration >=1 40ms.
Charge Control: Control on device front panel, press key on paddle.Prompts: Voice and visual prompts.
Manual Mode
Energy Selection: Selectable at2,5,7,10,20,30,50,70,100,150,200,300,360 joules.
Synchronized Mode: Synchronizes defibillator pulse to patient's R-wave. "SYNC" messagedisplayed on monitor
Optional
MB _pacer
MB_EtCO2
MB_NIBP
SPO2 Moudle
